WSG-Y16 V2 mini-YGDAI I/O Card

The Waves WSG-Y16 V2 I/O card for Yamaha digital consoles enables integration with Waves SoundGrid systems via a single Ethernet cable, providing live sound engineers with access to SoundGrid’s low-latency plugin processing, multitrack recording and playback, and audio networking. WSG-Y16 V2 also features clock Sync over Ethernet for syncing multiple consoles and performing digital splits.

Together with a SoundGrid DSP server and a Mac or PC, the Waves WSG-Y16 V2 card lets you process 16 channels of audio in low latency using SoundGrid-compatible plugins, directly from your Yamaha console.

Extremely low-latency networking platform for processing, playback and recording
Supports 44.1, 48, 88.2 and 96 kHz sample rates
16 I/O channels of audio at 44.1/48 kHz; 8 I/O channels of audio at 88.2/96 kHz
Clock Sync over Ethernet (SoE) for digital splits and audio networking
Works with all consoles installed with the WSG-Y16 V1 card
Redundancy and recovery options
Connects to SoundGrid systems and SoundGrid-compatible devices
Compatible with standard computers and switches
Comes with the SoundGrid Studio Application for ASIO/Core Audio recording and playback
MIDI control from consoles
Add up to four cards for 64/32-channel processing and recording

[ { "DocumentName" : "SoundGrid Studio + eMotion ST 8 Ch. Mixer", "SKU_MSRP" : 0.000000000, "SKUPrice" : 0.000000000, "SKUDepartmentID" : 10, "CouponPrice" : 0.00, "Discount" : 0, "CouponCode" : "", "Icon" : "https://img.wavescdn.com/1lib/images/products/mixers/icons/soundgrid-studio-emotion-st-8-ch.png", "DocumentUrlPath" : "/mixers-racks/soundgrid-studio-emotion-st-8-ch", "SKUNumber" : "EMSRCKSG", "SKUID" : 499, "ReviewsTotal" : 91, "Rating" : 4.15385, "Category" : "", "BadgeText" : "", "BadgeClass" : "", "CouponCampaignID" : 0, "SaleEndDate" : "", "GSFCategory" : "", "Note" : "%3cdiv+class%3d%22react-list-page__buy-button%22%3e%0d%0a%3ca+class%3d%22buy-btn%22+href%3d%22%2faccount%2fsoundgrid-studio-free%22+data-gavalue%3d%22SoundGrid+Studio%22+data-gaevent%3d%22Free%22++title%3d%22Get+it+Free%22%3eGet+it+Free%3c%2fa%3e%0d%0a%3c%2fdiv%3e", "SKUEnabled" : "False", "IsInventory" : "", "IsPreorder" : "False", "ExpectedShipping" : "", "MainOrder" : 29999, "DocumentPageDescription" : "Record+and+monitor+with+plugins+in+real+time.+Mix+plugin-rich+sessions.+Collaborate+easily+with+other+musicians%2c+producers+and+engineers.+SoundGrid+Studio+unlocks+the+power+of+real-time+processing+and+networking+in+your+studio.", "VariantsMinimalPrice" : 0.000000000, "IsVariantsPriceSame" : "False", "IsProductOptions" : "False", "FixedPosition" : "False" }, { "DocumentName" : "StudioRack", "SKU_MSRP" : 0.000000000, "SKUPrice" : 0.000000000, "SKUDepartmentID" : 2, "CouponPrice" : 0.00, "Discount" : 0, "CouponCode" : "", "Icon" : "https://img.wavescdn.com/1lib/images/products/plugins/icons/studiorack1.png", "DocumentUrlPath" : "/plugins/studiorack", "SKUNumber" : "SRCKSG", "SKUID" : 522, "ReviewsTotal" : 177, "Rating" : 4.43503, "Category" : "", "BadgeText" : "", "BadgeClass" : "", "CouponCampaignID" : 0, "SaleEndDate" : "", "GSFCategory" : "", "Note" : "%3cdiv+class%3d%22react-list-page__buy-button%22%3e%0d%0a%3ca+href%3d%22%2faccount%2fstudiorack-free%22++class%3d%22buy-btn%22+data-gavalue%3d%22StudioRack%22+data-gaevent%3d%22Free%22+title%3d%22Get+it+Free%22%3eGet+It+Free%3c%2fa%3e%0d%0a%3c%2fdiv%3e", "SKUEnabled" : "False", "IsInventory" : "", "IsPreorder" : "False", "ExpectedShipping" : "", "MainOrder" : 29999, "DocumentPageDescription" : "Create+powerful+plugin+chains+with+the+new+Waves+StudioRack%2c+the+ultimate+plugin+chainer+%e2%80%93+now+enhanced+with+new+features+including+parallel+processing+racks%2c+multiband+split+racks%2c+and+macros+to+create+your+own+%e2%80%98custom+plugins.%e2%80%99", "VariantsMinimalPrice" : 0.000000000, "IsVariantsPriceSame" : "False", "IsProductOptions" : "False", "FixedPosition" : "False" } ]

Loading....

[ { "DocumentName" : "Proton Server SuperRack Combo for Yamaha", "SKU_MSRP" : 2669.000000000, "SKUPrice" : 2669.000000000, "SKUDepartmentID" : 9, "CouponPrice" : 0.00, "Discount" : 0, "CouponCode" : "", "Icon" : "https://img.wavescdn.com/1lib/images/products/hardware/icons/proton-server-superrack-combo-for-yamaha.png", "DocumentUrlPath" : "/hardware/proton-server-superrack-combo-for-yamaha", "SKUNumber" : "CMBPRYMH", "SKUID" : 860, "ReviewsTotal" : 0, "Rating" : 0, "Category" : "", "BadgeText" : "", "BadgeClass" : "", "CouponCampaignID" : 0, "SaleEndDate" : "6/7/2021 12:28:57 PM", "GSFCategory" : "", "Note" : "Out+of+stock+%e2%80%93+Shipping+Q4+2022", "SKUEnabled" : "False", "IsInventory" : "", "IsPreorder" : "True", "ExpectedShipping" : "", "MainOrder" : 20007, "DocumentPageDescription" : "An+affordable%2c+complete+system+for+mixing+live+performances+with+Waves%27+award-winning+SoundGrid+plugins+directly+on+your+Yamaha+console+in+ultra-low+latency.", "VariantsMinimalPrice" : 0.000000000, "IsVariantsPriceSame" : "False", "IsProductOptions" : "False", "FixedPosition" : "False" }, { "DocumentName" : "Server One-C Combo for Yamaha", "SKU_MSRP" : 3599.000000000, "SKUPrice" : 3599.000000000, "SKUDepartmentID" : 9, "CouponPrice" : 0.00, "Discount" : 0, "CouponCode" : "", "Icon" : "https://img.wavescdn.com/1lib/images/products/hardware/icons/server-one-c-combo-yamaha.png", "DocumentUrlPath" : "/hardware/server-one-combo-for-yamaha", "SKUNumber" : "CMBSG1CYMH", "SKUID" : 820, "ReviewsTotal" : 0, "Rating" : 0, "Category" : "", "BadgeText" : "", "BadgeClass" : "", "CouponCampaignID" : 0, "SaleEndDate" : "", "GSFCategory" : "", "Note" : "Out+of+stock+%e2%80%93+Shipping+Q4+2022", "SKUEnabled" : "False", "IsInventory" : "", "IsPreorder" : "True", "ExpectedShipping" : "", "MainOrder" : 20007, "DocumentPageDescription" : "With+this+hardware+and+software+combo+for+your+Yamaha+console%2c+you+can+harness+the+powerful+processing%2c+recording+and+sound-checking+capabilities+of+SoundGrid+when+on+the+road.", "VariantsMinimalPrice" : 0.000000000, "IsVariantsPriceSame" : "False", "IsProductOptions" : "False", "FixedPosition" : "False" } ]

Loading....

The following Yamaha consoles and mixers are compatible with the WSG-Y16 mini-YGDAI card:

Console Model	WSG-Y16 I/O cards
PM5D / PM10 / DM2000 / O2R96 / DME64N	x 4
M7CL / CL Series	x 3
DM1000 / LS9-32 / QL Series	x 2
LS9 / O1V96 / DME24N / TXn series	x 1

WSG-Y16 Card Manual WSG-Y16 Card Quick Setup Guide
